Since the establishment of its predecessor company in 1970. Under Otsuka Group's corporate philosophy “Otsuka-people creating new products for better health worldwide”, Otsuka Electronics, a company that provides solutions with the power of optics and cutting-edge technologies, develops, manufactures and markets optical/medical/industrial measurement devices and equipment.
Zeta-potential & Particle size Analyzer ELSZneo
ELSZneo is the high-end model of the ELSZ series. This instrument measures the zeta potential and particle size of both diluted and concentrated solutions, and the molecular weight of a polymer. As new features, ELSZneo provides a multi-angle measurement to improve the separability of particle size distribution, particle concentration measurement, microrheology measurement, and gel network analysis.
Main features
◎ Particle size and zeta potential measurement in a wide concentration range from diluted to concentrated solution
◎ Multi-angle measurement to carry out particle size distribution with higher separability
◎ Zeta potential measurement of solid surface in high salt concentration
◎ Particle concentration analysis using Static Light Scattering
◎ Microrheology measurement using Dynamic Light Scattering
◎ Gel network and gel heterogeneity analysis by measuring the intensity of scattered light and diffusion coefficient of the sample at multiple points
◎ Standard flow cell which can be used for two types of measurement (Particle size and zeta potential) without replacing samples
◎ Wide range of measurement temperature from０to 90℃
◎ Temperature gradient function which enables denaturation (melting temperature) analysis for proteins
◎ Electrophoretic mobility measurement and plot analysis for accurate zeta potential measurement
Standard Certification
ISO 22412:2017
Application
Best suitable for basic and applied research of particle characterization in the field of surface chemical, inorganic, semiconductor, polymer, food industry, biotechnology, pharmaceutical and medical as well as surface research of film and flat state sample.
◎ New functional material
Fuel cell(Carbon nanotube, Fullerene, Function film, Catalyst, Nano-metal)
Bionanotechnology ( Nano capsule, Dendrimer, Drug Delivery System(DDS)), Nanobubble
Biocompatible material
◎ Ceramic and paints
Ceramic(Silica, Alumina, TiO2)
Surface modification, dispersion control of inorganic sol
Dispersibility, durability and shelf life control of ink, carbon black and organic pigment
Slurry state sample
Color filter
Flocculation research
◎ Semiconductor
Alien objects research on silicon wafer
Interaction research of abrasive/additive on wafer surface
CMP slurry
◎ Polymer and Chemical
Emulsion dispersion stability to extend product shelf life
Surface modification of latex
Function research of polyelectrolyte
Process control of paper production and Pulp additive research
◎ Pharmaceutical and food
Emulsion dispersion stability to extend product shelf life
Dispersibility control of liposome and vesicle
Functionality of surfactant(Micelle)
Exosome,
Viruses, Virus-like particles(VLP)
Proteins
Specification
Zeta-potential & Particle size Analyzer ELSZ-2000 series
In addition to existing zeta potential and particle size measurement, molecular weight analysis function is newly added. (Particle size :0.6nm-10um/Concentration range: 0.00001%-40%).
Electro-osmosis measurement enables high precision analysis of zeta potential using micro-volume (130ul) disposable cell.
Furthermore new auto temperature gradient function with extended range between 0 and 90℃ makes melting point and phase transition point analysis possible.
Main features
Higher sensitivity and shorter measure time with new APD.
Melting point and phase transition point analysis enabled by auto temperature gradient function.
Wide temperature range between 0 and 90℃.
High precision zeta potential analysis thanks to electro-osmosis measurement and plot analysis.
Supports zeta potential measurement of salt condensed sample.
Surface zeta potential of smaller area sample.
Standard Certification
ISO 22412:2017
Application
Best suitable for basic and applied research of particle characterization in the field of surface chemical, inorganic, semiconductor, polymer, food industry, biotechnology, pharmaceutical, and medical as well as surface research of film and flat state samples.
◎ New functional material
Fuel cell(Carbon nanotube, Fullerene, Function film, Catalyst, Nano-metal)
Bionanotechnology ( Nano capsule, Dendrimer, DDS), Nanobubble
◎ Ceramic and paints
Ceramic(Silica, Alumina, TiO2)
Surface modifier, dispersion, and cohesion of inorganic sol
Dispersion and cohesion of carbon black and organic pigment
Slurry state sample
Color filter
Flotation adsorption research
◎Semiconductor
Alien objects research on a silicon wafer
Interaction research of abrasive/additive on a wafer surface
CMP slurry
◎ Polymer and Chemical
Emulsion dispersion and cohesion
Surface modifier of latex
Function research of polyelectrolyte
Process control of paper production and Pulp additive research
◎ Pharmaceutical and food
Emulsion dispersion and cohesion
Dispersion/Cohesion control of liposome and vesicle
Functionality of surfactant(Micelle)
Specification
Multi-sample nanometer particle size measurement system nanoSAQLA
Low price, uncompromising high performance
Non-invasive, non-distributive, one-button 5-sample continuous measurement
It measures in high speed (approx. 1 minute) and it is also lightweight and compact which is essential for use in laboratories, and this new optical system is able to measure multiple samples at one time with a wide concentration range from dilute to concentrated.
In addition, it is a new product not immersed in the liquid (non-immersion type), so contamination is not an issue and up to 5 samples can be measured without stopping, when used without the autosampler.
Main features
◎ Simple and quick one-time setup of up to 5 samples each under different conditions.
◎ Measures both dilute and highly concentrated samples
◎ Measures in approximately 1 min
◎ Includes temperature gradient function
◎ Contamination-free continuous measurement
Standard Certification
ISO 22412:2017
Application
It is suitable for basic and applied research on particle characterization in inorganic, semiconductor, polymer, food, biotechnology, pharmaceutical, medical and other fields.
Specification
Polymer Phase Structure Analyzer PP-1000
PP-1000 analyzes the structure of polymers and film in-situ (on site) and in real time by using the small angle light scattering method. This analyzer is able to analyze larger structures (μm order) compared to analyzers that use x-rays and neutron beams because it uses visible light.
Evaluation of optical anisotropy and analysis of spherulite diameter of crystalline film can be carried out from Hv scattering which uses polarizers. Analysis of polymer blend correlation length can be carried out from Vv scattering.
Main features
◎Measures scattering angle of 0.33 to 45 degrees in 10 msec at the fastest ※
◎Evaluates structures of submicron to several hundred micron size
◎Measures solution samples with specialized cells
◎Allows user to easily switch between Hv and Vv scattering with software
◎Can be set up in labs because it is a table-top type
Dynamic Measurement Evaluation
◎ Phase separation process of polymer blends
◎ Crystallization process of polymers
◎ Calculation of crystal size, crystallization growth rate
◎ Orientation state
◎ Aggregation process
◎ Thermoset process
◎Structure change when temperature change occurs
◎Structure change caused by stretching*
◎Curing process caused by ultraviolet light*
※When not using HDR function, When using HDR function 100msec～
*These items require separate consultation. Please feel free to contact us about details for these items.
Standard Certification
Application
◎ Packaging materials
◎ Electronic parts
◎ Automotive materials
◎ Materials for semiconductors
◎ Bottle material
◎ Polymer materials in various fields (gels, crystalline films, polymer arrow)
Specification
